RK3288 Industrial control box

Summary:
RK3288 industrial control box adopts Rui Xin Micro RK3288 four-core chip scheme, support Android/Linux operating system, RK3288 Mali-T76x series is based on ARM quad-core A17 32-bit CPU and GPU, supporting mainstream audio and video formats and picture decoding. With HDMI-4K output, Ethernet, WIFI, GPS, 4G / 5G module, RS232, USB, IO port expansion and other functions.
Scope of application:

RK3288 industrial control box is a multifunctional intelligent terminal control box, widely used in: advertising machine, Ai robot, self-service terminal, transportation, finance, industrial control, intelligent education, intelligent retail and other intelligent fields.
Features:

1. High definition: HDMI 2.0 supports 4K 60Hz output
2, support USB cable, TF card, computer and other upgrading methods
3. TF card /U disk is configured with screen parameters, which can be lit immediately after insertion, perfectly supporting display of various sizes and resolutions
4, perfect support industry mainstream release software, industry application software, that is, out of the box
5, perfect support industry mainstream USB/ serial port devices, printers, card reader, password keyboard, fingerprint instrument, camera, ID identification, two-dimensional code scanner, provide demo test program.
6. Highly integrated: It has Ethernet, WIFI, 4G / 5G, GPS, 2-way RS232, GPIO, 5-way USB extension and other interface modes.
